Rotech X3 POS Specs
Product Model
X3
Display
15.6" TFT LCD Panel
OS
Windows 10 IoT LTSC Windows 11 IoT LTSC Ubuntu
Processor
Intel® Core™ i3-1315U Processor 10M Cache, up to 4.50 GHz, Fan-Free Intel® Core™ i5-1335U Processor 12M Cache, up to 4.60 GHz, Fan-Free
Memory
1 x DDR4, SO-DIMM, 8GB (Max. 32GB)
Storage
1 x M.2 SSD 128GB (256GB/512GB Optional Nvme/SATA Adaptive)
Resolution
15.6“ Main Display: 1920*1080 11.6" Second Display: 1920*1080
Brightness
350 cd/m²
WIFI/BT
M.2 Key-E Slot 2230 WiFi2.4-5G/BT4.0 (Optional)
Tilt Angle
The Screen Supports 0 to 180 Degrees (Single Screen), the Base Supports 0 ~50 Degree
Power Adaptor
External Power Adapter, 24V-4A/96W
Ports
4x USB 3.0 +2 x USB 2.0； 2 x Serial Port； 1 x RJ11, 12V (compatible with 24V cash drawers)； 1 x LAN (10/100/1000Mb)； 1 x Mic-In/Speaker-out (Combo Jack)； 1 x DC In(4pin)； 1 x Power Switch (with indicator light)
Speaker
2 x 2W Speaker (Optional)
Environment
Operating Temperature: 0°C~40°C Storage Temperature: -15°C～70°C
Base Indicator
White, 230mm x 5.8mm x 2.8mm
Optional Components
11.6" /15.6" Second Display; MSR/MSR+iButton/Barcode Scanner
EMC Safety
CE/FCC/UKCA/RoHS
N.W./G.W.
15.6" Single Screen：5.3 / 6.1Kg 15.6"+11.6" Dual Screen: 7.3 / 8.1Kg
Dimensions (L*W*H)
15.6" Single Screen：373 x 194 x 310 mm 15.6"+11.6" Dual Screen: 372 x 189 x 322 mm
